Number of Doors Controlled
|
1 Door
|
2 Door
|
4 Door
|
|
Number of Readers Supported
|
2
|
4
|
4
|
|
Types of Readers Supported
|
26-bit Wiegand, others upon request
|
26-bit Wiegand, others upon request
|
26-bit Wiegand, others upon request
|
|
Number of Inputs
|
2 (Exit Device and Door Status, AUX)
|
6 (2 Exit Device, 2 Door Status, 2 AUX)
|
12 (4 Exit Device, 4 Door Status, 4 AUX)
|
|
Number of Outputs
|
2 (1-From C Relay for Lock and 1-Form C Relay for Aux Output)
|
4 (2-From C Relay for Lock and 2-Form C Relay for Aux Output)
|
8 (4-Form C Relay for Lock and 4-Form C Relay for Aux Output)
|
|
Number of Doors Controlled
|
1 Door
|
2 Door
|
4 Door
|
|
Number of Readers Supported
|
2
|
4
|
4
|
|
Types of Readers Supported
|
26-bit Wiegand, others upon request
|
26-bit Wiegand, others upon request
|
26-bit Wiegand, others upon request
|
|
Number of Inputs
|
2 (Exit Device and Door Status, AUX)
|
6 (2 Exit Device, 2 Door Status, 2 AUX)
|
12 (4 Exit Device, 4 Door Status, 4 AUX)
|
|
Number of Outputs
|
2 (1-From C Relay for Lock and 1-Form C Relay for Aux Output)
|
4 (2-From C Relay for Lock and 2-Form C Relay for Aux Output)
|
8 (4-Form C Relay for Lock and 4-Form C Relay for Aux Output)
|
|
Card Holders Capacity
|
30,000
|
30,000
|
30,000
|
|
Log Events Capacity
|
100,000
|
100,000
|
100,000
|
|
Weight
|
7.4lbs (3.35kg)
|
7.5lbs (3.4kg)
|
7.8lbs (3.55kg)
|
|
Communication
|
TCP/IP and RS-485
|
TCP/IP and RS-485
|
TCP/IP and RS-485
|
|
Enclosure
|
Powder Coated Aluminium
|
Powder Coated Aluminium
|
Powder Coated Aluminium
|
|
Mounting
|
Wall Mount
|
Wall Mount
|
Wall Mount
|
|
Recommended Power Supply
|
12V DC, 1.5A
|
12V DC, 1.5A
|
12V DC, 1.5A
|
|
Dimensions (Bundle Only)
|
15in.×3.15in.×11in.
380mm(L) X 80mm(W) X 280mm(H)
|
15in.×3.15in.×11in.
380mm(L)×80mm(W)×280mm(H)
|
15in.×3.15in.×11in.
380mm(L)×80mm(W)×280mm(H)
|
|
Dimensions ( Board Only)
|
6.3in.×4.17in.
(160mm×106mm)
|
6.3in.×4.17in.
(160mm×106mm)
|
6.3in.×4.17in.
(160mm×106mm)
|
